Tech Specification
 |
 |
 |
 |
 |
 |
 |
Specification
| Model Name: | ASUS RT-AX82U DUAL BAND AX5400 GAMING ROUTER |
| Brand: | ASUS |
| Color: | Black |
| Network Standard: | IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11ax IPv4 IPv6 |
| Product Segment: | AX5400 ultimate AX performance: 574+4804 Mbps |
| AX technology: | Yes |
| Data Rate: | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps 802.11n : up to 300 Mbps 802.11ac (1024QAM) : up to 4333 Mbps 802.11ax (2.4GHz) : up to 574 Mbps 802.11ax (5GHz) : up to 4804 Mbps |
| Antenna: | External antenna x 4 |
| Transmit/Receive: | 2.4 GHz 2 x 2 5 GHz 4 x 4 5 GHz-2 4 x 4 |
| Processor: | 1.5 GHz tri-core processor |
| Memory: | 256 MB Flash 512 MB RAM |
| Boosts speed: | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
| Operating Frequency: | 2.4G Hz / 5 GHz |
| Ports: | RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4 USB 3.2 Gen 1 x 1 |
| Button: | WPS Button, Reset Button, Power Switch, LED on/off |
| LED Indicator: | Power x 1 2.4G x 1 5G x 1 WAN x 1 |
| Power Supply: | AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 1.75 A current |
| Package content: | RT-AX82U Router RJ-45 cable Power adapter Quick start guide |
| Product Weight (g): | 740 g |
| AiMesh: | AiMesh : Yes Primary AiMesh router : Yes AiMesh node : Yes |
| Router APP: | ASUS Router APP : Yes |
| Game: | Game Boost/acceleration : Yes |
| Alexa: | Support Alexa skil : Yes |
| IFTTT: | Support IFTTT : No |
| AiProtection: | AiProtection : AiProtection Pro Router Security Assessment : Yes Malicious site blocking : Yes Two-Way IPS : Yes Infected Device Prevention and Blocking ; Yes |
| Parental Control: | Parental Control : Yes Parental Control Customized Internet schedule : Yes |
| Traffic Control: | Adaptive QoS : Yes Bandwidth Monitor : Yes Bandwidth limiter : Yes Maximum Bandwidth limiter rule : 32 Traditional QoS : Yes Maximum Traditional QoS rule : 32 Traffic Monitor : Yes Real-time traffic monitor : Yes Wired Traffic Monitor : Yes Wireless Traffic Monitor : Yes Traffic Analyzer : Yes Traffic analysis period : Daily, Weekly, Monthly Website history : Yes |
| Wireless: | |
| IPv6 : | Yes |
| MU-MIMO : | Yes |
| Wi-Fi Encryption : | WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support |
| UTF-8 SSID : | Yes |
| Guest Network : | Yes |
| Maximum Guest Network rule : | 2.4GHz x3, 5GHz x3 |
| WPS : | Yes |
| Wi-Fi MAC address filter : | Yes |
| Maximum MAC filters : | 64 |
| Wireless scheduler : | Yes |
| Airtime fairness : | Yes |
| RADIUS Server : | No |
| Universal beamforming : | Yes |
| Explicit beamforming : | Yes |
| IGMP snooping : | Yes |
| WAN: | |
| Internet connection Type : | PPPoE, PPTP, L2TP, Automatic IP, Static IP |
| Dual WAN : | Yes |
| WAN Aggregation : | Yes |
| 3G/4G LTE dongle : | Yes |
| Android tethering : | Yes |
| Port forwarding : | Yes |
| Maximum port forwarding rule : | 64 |
| Port triggering : | Yes |
| Maximum port triggering rule : | 32 |
| DMZ : | Yes |
| DDNS : | Yes |
| NAT Passthrough : | PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, PPPoE relay |
| LAN: | DHCP Server : Yes IPTV : Yes LAN Link Aggregation : Yes Manually assign IP address : Yes Maximum manually assign IP address rule : 64 |
| VPN: | VPN Client L2PT : Yes VPN Client OVPN : Yes VPN Client PPTP : Yes VPN Server IPSec : Yes VPN Server OVPN : Yes VPN Server PPTP : Yes VPN Fusion : No |
| USB application: | File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 3G/4G LTE dongle : Yes HDD hibernation : Yes Safely Remove disk : Yes AiCloud : Yes Download master : Yes AiDisk : Yes Media Server : Yes Time Machine : Yes Samba Server : Yes FTP Server : Yes Shared Folder privileges : Yes |
| Administration: | Operating mode : Wireless router mode Access point mode Media bridge mode Repeater mode AiMesh node mode Operating system : ASUSWRT Free OS upgrade : Yes Firewall : Yes Maximum Firewall keyword filter : 64 Maximum Firewall network service filter : 32 Maximum Firewall URL filter : 64 Wake on LAN (WOL) : Yes SSH : Yes Configuration backup and restore : Yes Diagnosis tools : Yes Feedback system : Yes System log : Yes |
